Flex TS 92 18-EC - Unpacking and Checking Contents

34
TS 92 18-EC
Max. rip
capacity on
the left side of
the blade
mm 427
Weight
according
to”EPTA
Procedure
01/2003”
kg 23
Battery 18v
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
Weight of
battery
Kg
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
0.4
0.7
1.1
Working
Temperature
-10
󰦊
40℃
Storage
Temperature
-40
󰦊
70℃
Charging
temperature
4~40℃
Charger
CA 12/18, CA 18.0-LD,
CA 10.8/18.0
Overview (Figure A)
The numbering of the product features refers
to the illustration of the machine on the
graphics page.
1 Smart guard system
2 Anti-kickback device
3 Miter gauge
4 Variable-speed dial
5 Auto-stop indicator
6 Auto-stop button
7 Power switch
8 Elevation wheel
9 Bevel lock lever
10 Battery level indicator button
11 Battery level indicators
12 Push stick
13 Blade bevel scale
14 Rail locking lever
15 Rail adjustment knob
16 Rip fence lock lever
17 Rip fence
18 Dust tube
19 Blade wrench
20 Allen key
21 Smart guard system holder
22 Dust port
23 Dust bag
24 Vacuum adapter
Assembly
WARNING!
Avoid unintentional starting of the machine,
during assembly on the machine, always
remove the battery pack from the saw.
Before switching on the power
tool
Unpack the cordless table saw and check that
there are no missing or damaged parts.
Unpacking and checking contents
WARNING!
If any parts are missing, do not turn the switch
on until the missing parts are obtained and
are installed correctly.
Unpack the table saw and check if all parts
listed below:
–
Miter gauge
–
Push stick
–
Smart guard system
–
Riving knife
–
Anti-kickback device
–
Rip fence
–
Dust tube
–
Dust bag
–
Vacuum adapter
–
Table insert
–
Blade wrench
–
5mm Allen key
Tools needed (not supplied)
–
4mm Allen key
–
Philips screwdriver
–
Flat screwdriver
–
Combination square
NOTE
Remove the styrofoam block and cable tie
before first use. Do not raise the saw blade
before removing styrofoam block, this could
damage the tool.
