35
TS 92 18-EC
Inserting/replacing the battery
󰀲
Press the charged battery into the power
tool until it clicks into place (see figure B).
󰀲
To remove, press the release button and
pull out the battery (see figure C).
CAUTION!
When the device is not in use, protect the
battery contacts. Loose metal parts may short
circuit the contacts; explosion and fire hazard!
Removing/installing the table
insert (see figure D1-D3)
WARNING!
The table insert must be locked in place at all
times.
To remove the table insert
󰀲
Use a flat screwdriver (not supplied) to
remove the cover (D-5) first.
󰀲
Place your index finger into the finger hole
(D-1) to lift and pull the table insert (D-2)
out toward the front of the saw.
To install the table insert
󰀲
Position the table insert tabs (D-3) into the
pockets and place the table insert (D-2)
down. Make sure the table insert is seated
properly and securely in place.
The table insert (D-2) contains four adjustment
screws (D-4) for adjusting the height of the table
insert. Use a flat screwdriver (not supplied) to
adjust the screws. The insert should be slightly
below the table at the front and slightly above
the table at the back.
Installing/removing the smart
guard system or riving knife (see
figure E1-E2)
WARNING!
Fully secure the smart guard system before
using the table saw. A loose smart guard
system may slip into the blade and be thrown
towards you.
To install the smart guard system or
riving knife
󰀲
Remove the battery.
󰀲
Raise the blade as high as it will go by
rotating the elevation wheel (8) clockwise
and set the blade perpendicular to the
table.
󰀲
Unlock the guard release lever (E-1) by
rotating it clockwise.
󰀲
Slide the smart guard system (1) or riving
knife (E-3) into the mounting position
behind the release lever. Align and engage
the notches (E-2) in the smart guard system
or riving knife with the pin.
󰀲
Lock the guard release lever (E-1) by
rotating it counterclockwise.
To remove smart guard system or riving
knife
󰀲
Unlock the release lever (E-1) and pull
the guard toward the release lever to
disengage the notches (E-2) in the guard
system or riving knife from the pin.
󰀲
Pull the guard system or riving knife out.
Installing/removing the anti-
kickback device (see figure F)
WARNING!
Always install the anti-kickback device onto
the smart guard system when performing
“through cutting” operations.
To install the anti-kickback device
󰀲
Remove the battery.
󰀲
Press the release button (F-2) and position
the anti-kickback device (2) on the top edge
of the smart guard system (1), below the
notch (F-1).
󰀲
Press the anti-kickback device (2) down
until it drops into the notch (F-1).
To remove the anti-kickback device
Press the release button (F-2) and remove it.
Changing the blade (see figure
G1-G2)
WARNING!
Always wear gloves when changing or
handling blades. Blade tips can cause
personal injury.
󰀲
Remove the battery and table insert.
󰀲
Raise the blade (G-2) as high as it will go.
󰀲
Remove the smart guard system (1).
󰀲
Lift up the arbor lock lever (G-1) and slowly
rotate the blade (G-2) by hand until the lock
fully engages the saw’s arbor shaft (G-4)
and stops rotation.
󰀲
Loosen the arbor nut (G-5) counterclockwise
with the blade wrench (19) provided.
