Flexispot EF1 - Step 4: Install Supporting Plate; Step 5: Connect Desktop and Hand Switch; Step 6: Secure Frame Components; Step 7: Install Baffle and Power Adapter

C
x4
A
5x5
Install the power adaptor, desktop and hand switch
Connect the desktop and the
hand switch(12) with screws(D),
then lock it with pistol drill.
D
x13
Self-prepare
The margins on the two
sides need to be not
larger than 200mm.
10
10
10
10
Connect the switch cord to the DC port
Connect the motor cord to theM1 port
2
1
STEP8
Connect all cables to the adaptor (7)
Use cable tie to fix all cables onto
the table top.
Tear off
Manage cables
Fix them
6
C
A
3
2
11
4
Install the adaptor holder (11) to the
supporting beam(4)
4
D
12
The hand switch should be
installed in the side of the
lifting column with motor.
B
x4
A
2.5x2.5
7
11
STEP7
Install baffle and power adaptor
Install the baffle (8) to the supporting beam (4) using
screws (B), and then lock with 2.5*2.5 wrench (A).
Insert
A
4x4
A
4
5
G
G
STEP6
Tighten the supporting beam and
the transition rod screws
Use a 4x4 wrench (A) to tighten the screws on the
supporting beam (4), tighten the nut on the transition
rod (5) with a nut wrench (G)
A
8
B
4
9
7
1
13
2
