Flexit SL4 R - 14 Final Check

29
S3 R Right model
S3 R Left model
S4 R/S7 Right model S4 R/S7 R Left model
SL4 R Right model
SL4 R Left model
Unit top - air flow direction
Kitchen Hood
Unit bottom - air flow direction
Kitchen Hood
COMMON
Kitchen Hood
14 Final Check
Control that:
• The duct insulation is in accordance with the manual and the technical documents
• Ducts are connected to the right nipples – check against the unit drawings below
• Adjustment has been carried out in accordance with the manual and ventilation data documentation
• The unit operates normally at all stages
• Heating switches on
The installer may be held liable for any incorrect or defective installation.
