9 Technical specification
Flexlock is CE marked and meets the requirements
Size 67 x 67 x 23 mm
Weight (without battery) 54 g
Temperature, surrounding +17° to +30° C
Humidity 20% till 75% relative humidity, non condensing
Battery 3V, min 1400 mAh, Lithium recommended by Swedstyle
HF emission Max 20dBμA at 10m
IP-code IP 20
Number of users max 200 users
Battery lifespan 3 years or 30 000 openings
RFID 13,56 MHz, ISO/IEC 14443 A &B, ISO/IEC 180092, ISO/IEC 15693
Compatible with Mifare Classic 1k, Mifare Classic 4k, Mifare DESFire,
Mifare Plus, Mini, Ultra Light, HID iClass 2k, iClass 4k,
iClass SE 2k, 32k NFC *
Reading distance < 25 mm with Swedstyle-cards, other cards or tags may have
shorter and varied reading distance.
Lock standard SS-EN 16014:2011, Dimensioned for DIN 4547 Class B
Electrical safety IEC/EN/UL 62368, CSA 22.2
EMC and EMR radio test ETSI 300 330-1/-2 and 301 489-1/-3, FCC Part 15B, ICES-003
