Flexologic FAMM - Preparation before Mounting; Mounting Plates

9
H. Kamerlingh Onnesweg 2
2408 AW Alphen aan den Rijn
The Netherlands
CONFIDENTIAL - THIS DOCUMENT MAY NOT BE DISCLOSED TO ANY THIRD PARTY OR USED FOR ANY
OTHER PURPOSE WITHOUT THE EXPRESS WRITTEN PERMISSION OF AV FLEXOLOGIC BV
CONFIDENTIAL
11. Preparation before mounting
This section describes the preparations to be made prior to mounting.
Step
Action
1
Select a job from the drop down menu.
2
Check if the correct cylinder size is set in the job description.
3
Open the safety fence
4
Place a cylinder
5
Close the safety fence
6
Click on X
7
DONE
12. Mounting plates
This section describes how to start mounting plates onto the cylinder.
Step
Action
1
Check if the correct sleeve size is inside the machine.
Check if the plate(s) is/are on the conveyor belt.
2
Click on “Mount” in the home screen (A).
3
Click on “Start” in the mounting screen (A).
4
The machine will start mounting the plates.
5
DONE
Comments
A
A
