FlexRadio Systems FLEX-6500 User Manual

FLEX-6000 Signature Series – FLEX-6000 Hardware Reference Manual
Page 14 of 48
Copyright 2016 FlexRadio Systems. All Rights Reserved.
4 SPECIFICATIONS
4.1 GENERAL
Specification
FLEX-6300
FLEX-6500
FLEX-6700/R
Frequency Range (Transmitter)
Note: not applicable to the FLEX-
6700R
 Rated Output Power @
100W nominal
160m - 6m (Amateur
bands only by country)
160m - 6m (Amateur
bands only by country) +
MARS
160m - 6m (Amateur
bands only by country) +
MARS
 Transverter (XVTR) IF
Output Port
100 KHz - 54 MHz
100 KHz - 77 MHz
100 KHz - 77 MHz
135 - 165 MHz
Frequency Range (Receiver)
 Low Band (First Nyquist
Zone)
30 kHz – 54 MHz
30 KHz to 77 MHz
30 KHz - 77 MHz
 High Band (Second
Nyquist Zone)
NA
NA
135 - 175 MHz
Emission Modes*
A1A (CW), A3E(AM), J3E
(SSB) , F3E (FM)
A1A (CW), A3E(AM), J3E
(SSB), F3E (FM)
A1A (CW), A3E(AM), J3E
(SSB) , F3E (FM)
Frequency Stability
 Standard
0.5ppm TCXO
0.5 ppm TCXO
0.02 ppm OCXO (60 sec
@ 25C)
 With GPSDO Option (GPS
Locked)
NA
5x10
-12
over 24 Hours
5x10
-12
over 24 Hours
Antenna Impedance - Unbalanced
50 Ohms
50 Ohms
50 Ohms
Antenna Tuner Load Range -
Unbalanced
8.3 - 300 Ohms (80m –
10m)
6.7 - 150 Ohms (160m
and 6m)
8.3 - 300 Ohms (80m –
10m)
6.7 - 150 Ohms (160m
and 6m)
8.3 - 300 Ohms (80m –
10m)
6.7 - 150 Ohms (160m
and 6m)
Standard Supply Voltage
+13.8 VDC +/- 15%
+13.8 VDC +/- 15%
+13.8 VDC +/- 15%
(FLEX-6700)
100-240 VAC, 50-60 Hz
(FLEX-6700R)
Supply Current (Receive/Transmit)
1.7A Receive Typ., 23A
Transmit Max.
2A Receive Typ., 23A
Transmit Max.
2A Receive Typ., 23A
Transmit Max. % (FLEX-
6700)
5W Standby/50W
operating (FLEX-6700R)
Operating Temperature Range
0 to +50C, +32 to +122F
0 to +50C, +32 to +122F
0 to +50C, +32 to +122F
Dimensions
 With Feet
13"W x 11.75"D x
3.875"H, 33cm x 29.8cm
x 7.1cm
13"W x 12"D x 4"H,
33cm x 30.5cm x 10.2cm
13"W x 12"D x 4"H,
33cm x 30.5cm x 10.2
cm
 Without Feet (2U Rack
Height)
NA
13"W x 12"D x 3.5"H,
33cm x 30.5cm x 8.9 cm
13"W x 12"D x 3.5"H,
33cm x 30.5cm x 8.9 cm
 Weight
10 lbs., 4.5 kgs
13 lbs., 5.9 kgs
13 lbs., 5.9 kgs
10 lbs., 4.53 kgs (FLEX-
6700R)
* - Other modes may be available through the addition of third-party waveform plug-ins.

FlexRadio Systems FLEX-6500 Specifications
