–1–
POWER REQUIREMENTS
POWER SUPPLY
The AVT-1498 is designed for 12 Volt operation.
CAR BATTERY OPERATION
A cigarette lighter adapter cable is supplied for use in any 12 Volt, negative ground battery vehicle. Simply
insert the DC plug on the end of the cable into the DC POWER JACK (10) on the back of the TV set, and the
other end of the cable into the cigarette lighter receptacle of the vehicle. The television is now ready for
operation.
Remove plug from cigarette lighter receptacle when unit is not in use
CAUTION:
MEASURE DC SOURCE
POLARITY BEFORE USE
OTHERWISE, THE SET
MAY BE DAMAGED.
GND
Car battery cord
DC JACK
(Rear of TV)
DC JACK
Cigarette Lighter
socket of car (12V)
•
FUSE
T5A/250V
EXT. SPK.
DC INPUT
12-14V
ANT.
INPUT-1
VIDEO AUDIO
OUT
VIDEO AUDIO
DC
12-14V
INPUT-3
VIDEO AUDIO
+
–
CAUTION:FOR CONTINUED PROTECTION
AGAINTS RISK OF FIRE REPLACE ONLY
WITH SAME TYPE 5A, 250V FUSE.
REVISED DATE : 07/04/03
– DRAWING CHANGE
*
*
