2. Operation (Restoration & Discharge)
PROGRAM MODE – PULSE SCENARIOS
Discharge Method - Pulse Scenarios (Patterns)
( V = Voltage, A = Ampere, T = Time )
Pulse 1
Discharge Pulse 1 Scenario :
① Start Discharging with Set A.
② When Actual V reaches Set V, it will finish the
M
o
de regardless of Set Time.
③ When it reached Set T, it will also finish the
Mo
de even though it has not reached Set V.
Pulse 2
Discharge Pulse 2 Scenario :
① Start Discharging with Set A. (Constant Current)
② When Actual V reaches Set V, it maintains Set V by
c
o
ntrolling Actual A. (Constant V).
③ When it reaches Set T, it will finish the Mode.
You should check specification & conditions of used batteries before you input Set V, Set A and
Set Time for regeneration of batteries. Wrong set values will cause damage to batteries due to
over charge or other reasons.
