2. Operation (Restoration & Discharge)
PROGRAM MODE – PULSE SCENARIOS
Restoration(regeneration charge) Method – Pulse Scenarios(Patterns)
( V = Voltage, A = Ampere, T = Time )
Pulse 5
Restoration Pulse 5 Scenario :
① Start Charging with Set A for 10 minutes .
▶Keep Zero (0) Ampere for 5 minutes.
② Repeat ① continuously until Set T, then stop.
③ Except, when it reaches Set V, maintain Set V
by
controlling Actual A. (Constant Mode)
Pulse 6
Restoration Pulse 6 Scenario :
① Start Charging with Set A until it reaches Set V.
(sam
e as pulse 1)
② But when Actual Voltage suddenly drops to 0.2V
du
ring Charge, it will finish the Mode regardless
of Set Time.
③ If this (drop by 0.2V) does not happen it will
co
ntinue until Set Time and finish the Mode.
You should check specification & conditions of used batteries before you input Set V, Set A
and Set Time for regeneration of batteries. Wrong set values will cause damage to batteries
due to over charge or other reasons.
44
