PAGE 4-1A REPAIR PARTS
CENTRIFUGAL PUMP REPAIR PARTS
“CJ103” SERIES
(For Pricing Refer To Repair Parts Price List)
HP 1/3 1/2 3/4 1 1-1/2 2
STAGE 1 1 1 1 1 1
ITEM
SINGLE PHASE
BRASS IMPELLER
MODEL
NO.
CJ103031 CJ103051 CJ103071 CJ103101 CJ103151 CJ103201
THREE PHASE
BRASS IMPELLER
CJ103053 CJ103073 CJ103103 CJ103153 CJ103203
SINGLE PHASE
PLASTIC IMPELLER
CJ103P031 CJ103P051 CJ103P071 CJ103P101 CJ103P151 CJ103P201
THREE PHASE
PLASTIC IMPELLER
CJ103P053 CJ103P073 CJ103P103 CJ103P153 CJ103P203
DESCRIPTION
PART
NO.
QTY.
1
1
Motor, Nema J - 1PH
Motor, Nema J - 3 PH
Motor Access Cover
Screws, Access Cover
021301R
021302
98J103
—
1
2
98J105
98J305
1
2
98J107
98J307
1
2
98J110
98J310
1
2
98J115
98J315
1
2
98J120
98J320
1
2
‡
2
3
4
5
5A
5B
6
Slinger Washer
Mounting Ring
Hex Hd. Cap Screws 3/8 x 3/4”
Seal, Rotary w/Spring
Impeller - Brass
Impeller - Plastic
Clearance Ring
Ring, Square Cut †
126905
134107
*
131100
132583
1
1
4
1
130403A
133426
N/A
1
1
1
4
1
126900A
139222
138138
1
1
1
4
1
127805
021280
134240
1
1
1
4
1
127804
135248
134240
1
1
1
4
1
127806
021279
134240
1
1
1
4
1
127848
N/A
N/A
1
7
‡
8
Body Assembly - Brass Impeller
Body Assembly - Plastic Impeller
Suction Clearance Ring-Brass
Pipe Plugs, 1/8” NPT
021439
*
127870
1
127869A
4
127870
1
127869A
4
127780
1
N/A
4
127780
1
N/A
4
127780
1
N/A
4
127780
N/A
N/A
4
9
10
Hex Hd. Cap Screws 3/8 x 1”
Base
*
125855
4
1
4
1
4
1
4
1
4
1
4
1
(*) Standard hardware item
(‡) Not shown
(†) For pumps with paper gasket, replace with part number 127782
(
∆) Kit Includes: Access Cover, Screws & Wiring Diagrams
