INSPECTION AND STORAGE
When unpacking the unit, inspect carefully for any
damage that may have occurred during shipment.
If the unit is received sometime before it can be
used, it should be inspected, recrated and stored
in a dry location.
LOCATION
IMPORTANT: In installations where property
damage might result from an inoperative or
leaking pump due to power outages, discharge
line blockage or any other reason, a back-up
system (s) and/or warning system (s) should be
used.Install a gate valve and union in the suction
and discharge lines. For removal of the pump for
service, close the gate valve and disconnect the
union.
1. Locate pump as close to the fluid source as
possible.
2. Place unit where the motor electrical
components and piping are protected from the
weather and extremes of heat, humidity and
below freezing temperatures.
3. Mount unit in a dry location that is easily
accessible for inspection and maintenance. If
a dry location is not available, mount it on a
foundation well above the wet floor.
4. Allow ample clearance around unit for free air
circulation.
5. CJ103 Series pumps incorporate a discharge
port on the pump casing that can be adjusted
in 90 increments. If necessary, adjust the
discharge port to accommodate the specific
application. Pump performance will not be
affected by the position of the discharge port.
SUCTION LIMITATIONS
1. Units are non self-priming. Normally after
being primed the total suction lift of the pump
is 25 feet. Suction lift varies depending upon
elevation (altitude) and water temperature. See
Practical Suction Lift chart.
2. Where liquids at or near their boiling points
are being handled, the supply must be located
above the suction, so that the available NPSH
will be greater than that required by the unit.
Pump Performance Chart D
To convert to feet of head, multiply by 2.31.
* Operation of pump in this range may result in m otor damage.
Do not exceed the maximum case pressure and maximum liquid temperature rating of the pump.
Suction & Discharge Tapping: 1-1/2” X 1-1/4”
Motor Voltage: Single phase: 1/3 - 115V; 1/2 thru 2 HP - 115/230V; 3 HP - 230V, 60HZ
Three phase: 1/2 thru 2 HP - 208-230/460V - 50/60HZ
3 HP - 208-230/460V - 60HZ
Single
Phase
Model No.
Three
Phase
Model No.
HP Stage
GPM at Total Pressure in PSI
Max.
Press.
PSI
Max.
Case
Press.
PSI
Max.
Liquid
Temp.
15 20 25 30 35 40 50 60 70 80 90
BRASS IMPELLER MODELS
CJ103031 - 1/3 1 41 30 10 27 10 0 200°F
CJ103051 CJ103053 1/2 1 48 40 27 30 10 0 200°F
CJ103071 CJ103073 3/4 1 62 58 46 31 33 10 0 200°F
CJ103101 CJ103103 1 1 70 66 58 48 34 40 10 0 200°F
CJ103151 CJ103153 1-1/2 1 * 75 70 61 51 36 44 10 0 200°F
CJ103201 CJ103203 2 1 * * 79 77 68 57 45 100 200°F
CJ101B071 CJ101B073 3/4 2 * * 32 29 25 22 5 53 160 200°F
CJ101B101 CJ101B103 1 2 * * 35 32 29 27 23 3 62 160 200°F
CJ101B151 CJ101B153 1-1/2 2 * * 42 39 37 34 28 19 68 160 200°F
CJ101B201 CJ101B203 2 2 * * 45 44 43 40 34 26 70 160 200°F
CJ101C201 CJ101C203 2 3 * * 42 41 40 38 35 31 27 20 7 93 160 200°F
CJ101C301 CJ101C303 3 3 * * 51 50 49 43 41 40 35 29 21 95 160 200°F
THERMOPLASTIC IMPELLER MODELS
CJ101P071 CJ101P073 3/4 2 * * 31 28 23 20 48 160 160°F
CJ101P101 CJ101P103 1 2 * * 34 31 30 29 19 60 160 160°F
CJ101P151 CJ101P153 1-1/2 2 * * 46 44 41 37 31 14 61 160 160°F
CJ101P201 CJ101P203 2 2 * * 45 44 42 39 31 21 65 160 160°F
CJ101D201 CJ101D153 2 3 * * 41 40 38 37 33 29 24 17 89 160 160°F
CJ101D301 CJ101D303 3 3 * * * 46 45 45 42 38 33 27 18 93 160 160°F
