Flint & Walling PB1014S101 User Manual

14
© 2020 FLINT & WALLING, INC. • 95 North Oak St. • Kendallville, IN 46755
flintandwalling.com
FORM NO. FW0045
1020
SUPERSEDES 1114
PRESSURE BOOSTER PUMP REPAIR PARTS
(For Pricing Refer To Repair Parts Price List)
Replacement Motors
10 9
ITEM REPLACEMENT MOTORS QTY CAST IRON
POWDER
COATED
STAINLESS
STEEL
CAST IRON
POWDER
COATED
STAINLESS
STEEL
SINGLE PHASE 60 HZ THREE PHASE 60 HZ
9
ODP NEMA J 1/3 HP
1
98J103 98J103 98S103
ODP NEMA J 1/2 HP 98J105 98J105 98S105 98J305 98J305 98S305
ODP NEMA J 3/4 HP 98J107 98J107 98S107 98J307 98J307 98S307
ODP NEMA J 1 HP 98J110 98J110 98S110 98J310 98J310 98S310
ODP NEMA J 1-1/2 HP 98J115 98J115 98S115 98J315 98J315 98S315
ODP NEMA J 2 HP 98J120 98J120 98S120 98J320 98J320 98S320
ODP NEMA J 3 HP 98J630 98J630 98S630 N/A N/A N/A
10 Motor Cover w/Screws 1 023212 023212 023212 023212 023212 023212
* Screws, Motor Cover 2 021302 021302 021302 021302 021302 021302
SINGLE PHASE 50 HZ THREE PHASE 60/50 HZ
9
ODP NEMA J 1/3 HP
1
98J003 98J003 98S003
ODP NEMA J 1/2 HP 98J005 98J005 98S005 98J305 98J305 98S305
ODP NEMA J 3/4 HP 98J007 98J007 98S007 98J307 98J307 98S307
ODP NEMA J 1 HP 98J010 98J010 98S010 98J310 98J310 98S310
ODP NEMA J 1-1/2 HP 98J015 98J015 98S015 98J315 98J315 98S315
ODP NEMA J 2 HP 98J820 98J820 98S820 98J320 98J320 98S320
10 Motor Cover w/Screws 1 023212 023212 023212 023212 023212 023212
* Screws, Motor Cover 2 021302 021302 021302 021302 021302 021302
SINGLE PHASE 60/50 HZ THREE PHASE 60/50 HZ
9
TEFC NEMA J 1/2 HP
1
020691 020691 021011 021011
TEFC NEMA J 3/4 HP 021008 021008 021012 021012
TEFC NEMA J 1 HP 021009 021009 020688 020688
TEFC NEMA J 1-1/2 HP 020692 020692 020647 020647
TEFC NEMA J 2 HP 020693 020693 020689 020689
TEFC NEMA J 3 HP 021010 021010 020690 020690
* Not Shown
N/A - Not available
