34
Fuel filling hole
Fuel tank ventilation valve
Fuel tank ventilation valve connector
Fuel tank filling hose connector
Fuel filter
(assembled to the fuel filling hose)
Engine
Fuel return hose
(only for diesel engines)
Fuel filling hose
Fuel level sensor
Fuel tank
The location of equipment may vary depending on the model or the equipment.
28. Fuel system functioning
ENG
