2.3 Select a Location
Select a suitable location to mount the camera.
For advice on positioning and orienting the camera, see the camera's installation
and user guide.
Verify that the operating temperature range is between -30°C ~ 60°C (-22° ~ 140°
F), 10-90% relative humidity (non-condensing).
For the list of mounting accessories available for the camera, see the FLIR
Security Cameras - Accessory Guide.
3. Install the Camera
3.1 Fit Mounting Hardware
If required, install the mounting hardware for the camera according to the
instructions for the hardware.
3.2 Remove Camera Cover
a. Using the Torx wrench, loosen the three Torx
screws counter-clockwise (1).
b. Gently pull the top cover away from the
camera body (2).
Internal Interfaces
Internal interface
Description
3
DEFAULT
To reset the camera to its factory defaults, press the Default
button for six seconds.
4
RESET
To reboot the camera, press the Reset button for one second.
5
Micro SD card slot
For recording and file storage, insert a microSDXC card (up to
256 GB, Class 10) in the card slot.
