FLIR C2 User Manual

Technical data8
8.5 FLIR C2 Educational Kit
P/N: 72002-0202
Rev.: 41167
NOTE
Only educational institutions are eligible for purchasing this product.
Imaging and optical data
NETD 100 mK
Field of view
41° × 31°
Minimum focus distance
• Thermal: 0.15 m (0.49 ft.)
• MSX: 1.0 m (3.3 ft.)
Focal length 1.54 mm (0.061 in.)
Spatial resolution (IFOV)
11 mrad
F-number 1.1
Image frequency 9 Hz
Focus Focus free
Detector data
Focal Plane Array Uncooled microbolometer
Spectral range
7.5–14 µm
Detector pitch 17 µm
IR sensor size 80 × 60
Image presentation
Display (color)
• 3.0 in.
• 320 × 240 pixels
Display, aspect ratio 4:3
Auto orientation Yes
Touch screen Yes, capacitive
Image adjustment (alignment calibration) Yes
Image presentation modes
Infrared image Yes
Visual image Yes
MSX
Yes
Gallery
Yes
Measurement
Object temperature range –10°C to +150°C (14 to 302°F)
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
(77°F) nominal.
#T559918; r. AN/42281/42281; en-US
29

FLIR C2 Specifications

General

Package weight	540 g
Battery life (max)	2 h
Battery recharge time	1 h

Weight and Dimensions

Depth	125 mm
Width	80 mm
Height	24 mm
Weight	130 g
