FLIR C2 User Manual

Technical data8
8.7 FLIR C3 (incl. Wi-Fi) Educational Kit
P/N: 72003-0404
Rev.: 41167
NOTE
Only educational institutions are eligible for purchasing this product.
Imaging and optical data
NETD 100 mK
Field of view
41° × 31°
Minimum focus distance
• Thermal: 0.15 m (0.49 ft.)
• MSX: 1.0 m (3.3 ft.)
Focal length 1.54 mm (0.061 in.)
Spatial resolution (IFOV)
11 mrad
F-number 1.1
Image frequency 9 Hz
Focus Focus free
Detector data
Focal Plane Array Uncooled microbolometer
Spectral range
7.5–14 µm
Detector pitch 17 µm
IR sensor size 80 × 60
Image presentation
Display (color)
• 3.0 in.
• 320 × 240 pixels
Display, aspect ratio 4:3
Auto orientation Yes
Touch screen Yes, capacitive
Image adjustment (alignment calibration) Yes
Image presentation modes
Infrared image Yes
Visual image Yes
MSX
Yes
Gallery
Yes
Picture in Picture IR area on visual image
Measurement
Object temperature range –10°C to +150°C (14 to 302°F)
Accuracy ±2°C (±3.6°F) or 2%, whichever is greater, at 25°C
(77°F) nominal.
#T559918; r. AN/42281/42281; en-US
37

FLIR C2 Specifications

General

Package weight	540 g
Battery life (max)	2 h
Battery recharge time	1 h

Weight and Dimensions

Depth	125 mm
Width	80 mm
Height	24 mm
Weight	130 g
