FLIR C2 User Manual

Technical data8
Radio
Wi-Fi
• Standard: 802.11 b/g/n
• Frequency range:
◦ 2400–2480 MHz
◦ 5150–5260 MHz
• Max. output power: 15 dBm
Power system
Battery type Rechargeable Li-ion polymer battery
Battery voltage 3.7 V
Battery operating time 2 h
Charging system Charged inside the camera
Charging time 1.5 h
External power operation
• AC adapter, 90–260 VAC input
• 5 V output to camera
Power management Automatic shut-down
Environmental data
Operating temperature range –10°C to +50°C (14 to 122°F)
Storage temperature range –40°C to +70°C (–40 to 158°F)
Humidity (operating and storage) IEC 60068-2-30/24 h 95% relative humidity +25°C
to +40°C (+77°F to +104°F) / 2 cycles
Relative humidity
95% relative humidity +25°C to +40°C (+77°F to
+104°F) non condensing
EMC
• WEEE 2012/19/EC
• RoHs 2011/65/EC
• C-Tick
• EN 61000-6-3
• EN 61000-6-2
• FCC 47 CFR Part 15 Class B
Radio spectrum
• ETSI EN 300 328
• FCC 47 CSR Part 15
• RSS-247 Issue 1
Magnetic fields EN 61000-4-8
Battery regulations UL 1642
Encapsulation Camera housing and lens: IP 40 (IEC 60529)
Shock 25 g (IEC 60068-2-27)
Vibration 2 g (IEC 60068-2-6)
Drop 2 m (6.6 ft.)
Physical data
Weight (incl. Battery) 0.13 kg (0.29 lb.)
Size (L × W × H) 125 × 80 × 24 mm (4.9 × 3.1 × 0.94 in.)
Tripod mounting No
Housing material
• PC and ABS, partially covered with TPE
• Aluminum
Color Black and gray
#T559918; r. AN/42281/42281; en-US
39

FLIR C2 Specifications

General

Package weight	540 g
Battery life (max)	2 h
Battery recharge time	1 h

Weight and Dimensions

Depth	125 mm
Width	80 mm
Height	24 mm
Weight	130 g
