FLIR C2 User Manual

3,1
78,7
mm
4,91
124,6
mm
1,02 25,9
mm
Optical axis
1,78
45,3
mm
0,43
11
mm
1,31
33,4
mm
0,91 23,1
mm
0,58 14,8
mm
Camera with build-in IR lens f=1,54mm
Visual Optical axis
IR Optical axis
1 2 3 4 5 6 7 8 9 10
1 632 54
A B
C
D
E
F
G
H
F
C
E
G
D
A B
Scale
1:1
C
Size
Modified
R&D Thermography
AKZE
Basic Dimensions Flir Cx
T128439
1(2)
A2
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2012, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
2017-02-17

FLIR C2 Specifications

General

Package weight	540 g
Battery life (max)	2 h
Battery recharge time	1 h

Weight and Dimensions

Depth	125 mm
Width	80 mm
Height	24 mm
Weight	130 g
