FLIR C2 User Manual

Terms, laws, and definitions
14
Term Definition
Qualitative thermography thermography that relies on the analysis of thermal patterns to
reveal the existence of and to locate the position of
anomalies
12
Quantitative thermography
thermography that uses temperature measurement to deter-
mine the seriousness of an anomaly, in order to establish re-
pair priorities
12
Radiative heat transfer Heat transfer by the emission and absorption of thermal
radiation
Reflected apparent temperature apparent temperature of the environment that is reflected by
the target into the IR camera
13
Spatial resolution ability of an IR camera to resolve small objects or details
Temperature measure of the average kinetic energy of the molecules and
atoms that make up the substance
Thermal energy total kinetic energy of the molecules that make up the object
14
Thermal gradient gradual change in temperature over distance
13
Thermal tuning process of putting the colors of the image on the object of
analysis, in order to maximize contrast
#T559918; r. AN/42281/42281; en-US
58
12.Based on ISO 10878-2013 (en).
13.Based on ISO 16714-3:2016 (en).
14.Thermal energy is part of the internal energy of an object.

FLIR C2 Specifications

General

Package weight	540 g
Battery life (max)	2 h
Battery recharge time	1 h

Weight and Dimensions

Depth	125 mm
Width	80 mm
Height	24 mm
Weight	130 g
