FLIR CM78 - Description; Meter Parts

4 Description
4.1 Meter parts
Figure 4.1 Front view
1. Clamp jaw.
2. Jaw opening trigger
3. Function buttons, see section 4.3 Function buttons, page 10.
4. Work light.
5. Function switch, see section 4.2 Function switch, page 9.
6. LCD display.
7. Probe/thermocouple terminals.
#T559826; r. AD/ 9130/9130; en-US 8
