7 Technical specifications
7.1 General specifications
Display 4000-count with bar
Controls
• 8-position rotary switch
• Dedicated IR button
• 8 dedicated function buttons:
flashlight, IR, maximum/minimum,
Bluetooth, hold, range, mode,
peak
Backlight White LED
Work light White LED array
Measurement ranges
See section 7.2 Electrical range
specifications, page 25.
Sample rate 20 per second, nominal
Input impedance 10 MΩ (VDC and VAC)
AC voltage bandwidth 45–400 Hz
Power supply 6 × AAA (LR03) batteries
Battery life 100 hours, using alkaline batteries
Auto power off (APO) After 25 minutes (nominal) inactivity;
reset when the rotary switch is set to
OFF, then set to any position again
APO quiescent current
50 µA maximum
Over-current protection fuse No fuse
Measurement type
True RMS, crest factor ≤ 3 at full
scale up to 500 V, decreasing linearly
to ≤ 1.5 at 1000 V
Continuity test Visual and audible.Threshold is 30 Ω
#T559826; r. AD/ 9130/9130; en-US 24
