5 Operation
registered. The Peak hold function is available when measuring AC/DC current or
voltage.
1. With the meter set to AC/DC current or voltage measurement (see section
5.3 Current measurements, page 14 or 5.4 Voltage measurements, page 15)
press the
button to enter Peak mode.
2. Press the
button toggle between Pmax and Pmin modes.
• In Pmax mode, the
indicator is displayed.
• In Pmin mode, the
indicator is displayed.
3. Read the positive/negative peak value on the display.
4. To return to normal operation, press and hold the
button for 2
seconds.
5.14 Temperature units
The meter displays temperatures in ℃ or ℉. The temperature unit switch is lo-
cated in the battery compartment.
1. To avoid electrical shock, disconnect the meter if connected to a circuit, re-
move the probe/thermocouple leads from the terminals, and set the function
switch to the
position before attempting to switch the temperature unit.
2. Unscrew the battery compartment cover and remove the batteries.
3. Set the temperature unit switch to the desired position.
4. Fit the batteries in place and secure the battery compartment cover.
5.15 Streaming measurement data using Bluetooth
5.15.1 General
Some IR cameras from FLIR Systems support Bluetooth communication, and to
those cameras you can stream measurement data from the meter. The data is
then merged into the result table in the IR image.
Streaming measurement data is a convenient way to add important information
to an IR image. For example, when identifying an overheated cable connection,
you may want to know the current in that cable.
The Bluetooth range is 10 m (32 ft.) maximum.
#T559826; r. AD/ 9130/9130; en-US 21
