5 Operation
Note
The meter can also be set to display peak values only, see section 5.13 Peak
hold, page 20.
5.3.1 DC Zero
The DC Zero feature removes offset values and improves the accuracy of DC
current measurements.
1. Set the function switch to the
position.
2. Ensure that there is no conductor in the clamp jaws.
3. Press the
button to enter the DC Zero mode and store the offset value.
The
indicator is displayed.
4. Use the
button to toggle the display between offset applied (solid
indicator) and no offset applied (flashing indicator).
5. To exit the DC Zero mode, press and hold the
button. The indica-
tor disappears and the
indicator is displayed.
5.4 Voltage measurements
1. Set the function switch to the
position.
2. Insert the black probe lead into the negative COM terminal and the red probe
lead into the positive V terminal.
3. Use the
button to select AC or DC voltage measurement.
• The
indicator should be displayed for AC voltage measurements.
• The
indicator should be displayed for DC voltage measurements.
4. Connect the probe leads in parallel to the part under test.
5. Read the voltage value on the display.
Note
The meter can also be set to display peak values only, see section 5.13 Peak
hold, page 20.
#T559826; r. AD/ 9130/9130; en-US 15
