FLIR E50 User Manual

Camera parts
7
7.3 LCD and keypad
7.3.1 Figure
7.3.2 Explanation
1. Touch-screen LCD.
2. Navigation pad with center push.
3. Image archive button.
4. Button to operate the laser pointer.
5. On/off button.
Function:
• Push the
button to turn on the camera.
• Push and hold the
button for less than 5 seconds to put the camera in stand-
by mode. The camera then automatically turns off after 6 hours.
• Push and hold the
button for more than 10 seconds to turn off the camera.
6. Back button.
#T559845; r. AJ/37554/37554; en-US
15

FLIR E50 Specifications

General

Resolution	240 x 180 pixels
Image Storage	SD card
Focus	Manual
Image Frequency	60 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	3.1 MP
Digital Zoom	4x continuous
Measurement Presets	Yes
Laser Pointer	Yes
Battery Operating Time	4 hours
Spectral Range	7.5 – 13 µm
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° × 19°
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Image Modes	Thermal, MSX
Battery Type	Li-Ion battery
Weight	0.825 kg
