FLIR E50 User Manual

Working with image modes
15
15.1 General
You can choose between different image modes when capturing an image.
15.2 Types of image modes
These are the image modes you can choose from:
Thermal MSX (Multi Spectral Dynamic Imaging):
Using this mode, the camera captures infrared im-
ages where the edges of the objects are en-
hanced. Note that the label for each fuse is clearly
legible.
Thermal: Using this mode, the camera captures
an ordinary infrared image.
Picture-in-picture: Using this mode, the camera
captures an infrared image frame that is displayed
on top of a digital photo.
Digital camera: Using this mode, the camera cap-
tures an ordinary digital photo.
#T559845; r. AJ/37554/37554; en-US
37

FLIR E50 Specifications

General

Resolution	240 x 180 pixels
Image Storage	SD card
Focus	Manual
Image Frequency	60 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	3.1 MP
Digital Zoom	4x continuous
Measurement Presets	Yes
Laser Pointer	Yes
Battery Operating Time	4 hours
Spectral Range	7.5 – 13 µm
Operating Temperature Range	-15°C to +50°C
Storage Temperature Range	-40°C to +70°C
Thermal Sensitivity	<0.05°C at 30°C
Field of View	25° × 19°
Temperature Range	-20°C to +650°C
Display	3.5" LCD touchscreen
Image Modes	Thermal, MSX
Battery Type	Li-Ion battery
Weight	0.825 kg
