FLIR Extech IRC30 User Manual

CommentStructural drawing
Insulation deficiencies in an intermediate flow due
to improperly installed fiberglass insulation batts.
The air infiltration enters the room from behind the
cornice.
10552303;a2
Air infiltration in a concrete floor-over-crawl-space
due to cracks in the brick wall façade.
The air infiltration enters the room beneath the
skirting strip.
10552603;a2
Publ. No. T559580 Rev. a486 – ENGLISH (EN) – November 17, 2010 65
16 – Introduction to building thermography
