6 FlashSight Specifications
• Weight (excluding batteries):
• Nominal battery life:
Lithium Cells Alkaline Cells
7+ hours ~2.5 hours
• Number of pixels: 160 x 120 (uncooled microbolometer)
• Field-of-View:
Configuration Degrees
30 mm 13.3° x 9.9°
50 mm 8.3° x 6.3°
• Eyepiece eye relief: 25 mm (1 inch)
• Temporal NEdT:
Configuration Sensitivity (NEdT)
30 mm - f/1.6 <85 mK
50 mm - f/2.0 <85 mK
• Turn-on time:
Time Degrees
<4 seconds
above -10°C (14°F)
<30 seconds at -32°C (-26°F)
Note: The unit cold starts at -32°C and then operates from -40°C to +55°C
• Image-storage capacity: <
70 frames
• Format of stored images: 8-bit uncompressed bit-map (.BMP), approx.
20 kBytes each
• Operating Temperature Range: -40°C to +55°C (-40°F to +131°F)
• IP rating: 65
Configuration Weight
30 mm < 800 g (1.76 lbs)
50 mm < 840 g (1.85 lbs)
