FlashSight™ User’s Guide
Copyright © 2006, FLIR Systems, Inc. 431-0002-09-10 Version 100 14
• Shock resistance:
• 10,000 rounds M16 weapon-firing
• 70g half-sine, 11msec period, all axes
• Bench-handling per MIL-STD-810E, Method 516.4, Proc. VI
• EMI / EMC: CE Mark certified
Note
These specifications are subject to change without notice. See the FlashSight
Product Specification (ISC doc. 431-0001-01-09) for detailed requirements.
7 FlashSight Interfaces
• RS170A (NTSC) compatible-output (75-ohm load impedance) on an
SMA connector. (See Figure 14.) CCIR/PAL is available as an option.
Note
See the FlashSight Interface Control Document (ISC doc. 431-0001-01-20) for
detailed interface data.
Figure 14: Analog output connector. Note that the rubber covering must be
rotated up to expose the connector.
