Handling the camera16
16.16 Operating the laser pointer
16.16.1 Figure
16.16.2 Procedure
Follow this procedure to operate the laser pointer:
1. To turn on the laser pointer, push and hold the laser button.
2. To turn off the laser pointer, release the laser button.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
Note The symbol is displayed on the screen when the laser pointer is on.
16.16.3 Laser warning label
A laser warning label with the following information is attached to the camera:
16.17 Using the zoom function
16.17.1 General
You can zoom in on infrared images in preview or recall mode. This enables you to view
details in an image.
16.17.2 Procedure
Do one of the following:
• To zoom into a live image, choose Zoom on the second tab in the menu system, then
use the joystick.
• To zoom into a image in recall mode, push the
button left/right.
#T559157; r. AH/45951/45951; en-US
59
