EN-US English
• Pull the trigger: Freeze an image. The image is then frozen until the trigger is
released.
10. Mount for tripod adapter.
11. Attachment point for retractable lanyard.
12. Battery.
Screen elements
Figure
Explanation
1. NFPA firefighting mode. Multipurpose mode for the initial fire attack with life
rescuing operation and control of the fire.
2. Black and white firefighting mode. Multipurpose mode for the initial fire attack
with life rescuing operation and control of the fire.
3. Fire mode. Similar to the NFPA firefighting mode, but with a higher-temperature
starting point for the heat colorization.
4. Search and rescue mode. Optimized for maintaining high contrast in the infrared
image while searching for people.
5. Heat detection mode. Optimized for searching hotspots during overhaul after the
fire is out.
6. Temperature scale.
7. Spotmeter.
8. Battery condition indicator.
9. Spotmeter temperature.
NOTE
• The green icon color indicates that the camera automatically switches between the
high-sensitivity range and the low-sensitivity range, depending on the object.
• The blue icon color indicates that the temperature range is locked.
• NFPA = National Fire Protection Association, an international non-profit
organization (http://www.nfpa.org).
© 2013, Flir Systems, Inc. All rights reserved worldwide.
8
Publ. no. T559819, rev. A
