USER GUIDE 5
AUTOMATIC CALIBRATION
The camera has a mechanical shutter inside that periodically activates
and allows the thermal camera to do a calibration or image refresh.
When the shutter activates, the image will freeze for a brief period.
When the camera rst turns on, and periodically thereafter, the app
will perform an automatic calibration to provide an optimal image.
It is also possible to manually activate the shutter by tapping the
Calibration icon in the upper right on the main screen. Calibration
can be switched to manual by turning o Automatic Calibration in the
Settings Menu.
MSX ALIGNMENT CONTROL
The FLIR ONE is tuned to align thermal and visual images at a distance
of 3 meters. To view scenes close-up, use the MSX Distance slider
control. Tap MSX Distance control to activate the slider control, then
adjust the alignment by sliding the control. To exit the slider control,
simply tap the icon again.
LOCK SPAN
The Lock Span function locks the temperature range of colors in the
display to the scene you are looking at. Simply tap the Lock Span icon
to hold the range, and tap it again to return to auto-scaling of the
scene.
SETTINGS MENU
The Settings Menu allows the user to congure additional features on
the FLIR ONE, as described below.
SAVE LOCATION
If a mobile phone signal is available, the location will be added to
captured images. This makes it possible to see images on a map.
SAVE TO PHOTOS
Turn this on to save a copy of your images and videos in the phone’s
photo gallery. Images will always be stored in the FLIR ONE camera
regardless of this setting. Items already captured will not be copied.
TEMPERATURE UNIT
Use this setting to change the temperature unit of measure between
the Fahrenheit and Celsius scale.
MSX DISTANCE SLIDER
OFFSET
ALIGNED
