Dialog
Right
mouse
click on
radar icon
Set radar to XMIT / STBY x x
Reset radar x x
Configure radar parameters x x x x
Set unit position from GPS x x
Set Radar Server time from
GPS
x
Enable / disable ICD-0100 x
Enable / disable AXML x
Record targets / intruders x
Record radar data x x
Reset communication statistics x x
Loader x
Table 1 - Radar Console Functions vs. Login Level
2.2.1.1 Radar Symbology
This section defines the symbology for the radar icon located in the left-hand column of the radar
console. Colors have a specific meaning as well as the information embedded in the icon. Figure 4
provides an icon lexicon describing the various color codes and symbols.
