431-TS00-00-10, Revision 110 9
3Operating Your Scout Camera
3–1 Camera Features and Controls
Power2× zoom
White hot/
Display
Black hot/
Eyepiece
Lens cap
Capture
Brightness
SD Card
door
Battery
cover
Hot Shoe/
Tripod mount
Hot Shoe
power contacts
Adjustable
diopter ±2
Instalert
information@itm.com
1.800.561.8187 w ww . . co m

Table of Contents

Other manuals for FLIR Scout

Preview: Quick Start Guide
Quick Start Guide2 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the FLIR Scout and is the answer not in the manual?

FLIR Scout Specifications

General IconGeneral
Digital Zoom2x
Refresh Rate9 Hz
Image ProcessingDigital
DisplayLCD
Battery TypeLithium-ion
Battery Life>5 Hours
