1—Introduction Scout Operator’s Manual
2June 2011
1–1 Scout Camera Features
•Rugged design—Built to withstand the demands of outdoor use.
It is fully submersible (IP67).
•240×180 or 320×240 microbolometer sensor for excellent
image quality and clarity
•Hot Shoe—Provides convenient power input and video output.
•Choose the 19 mm lens with 24° field of view or include a
removable 2× optical extender. Or, for longer-range viewing a 65
mm lens with 7° field of view is available.
•Two-sided Hand Strap—Accommodates both left-handed and
right-handed users.
•Software upgrades using an SD card.
•SD Card Slot—Allows for storing captured still images and video
(Pro models only) on the removable SD card.
1
•USB 2.0 Connection—Rapid transfer of files from the camera to
a PC.
• Four rechargeable AA NiMH batteries—Provides up to 5 hours of
camera operation on a single charge.
1. Available only with the TS24 Pro, TS32 Pro, or TS32r Pro
models.
