Flo CoRe+ Max - Pedestal and CMS Installation Safety

5
Install the Communication Gateway prior to the Commissioning of the Station. The Communication Gateway is the
property of AddEnergie. Fees will be charged if the Gateway is damaged, lost or not installed according to the
installation guide.
Rotary Position
Charging station
current (A)
Recommended
circuit protection (A)
Recommended
Wire Gauge (AWG)
0
1
2
3
4
5
6
7
8
9
80
72
64
59
56
48
40
32
24
16
100
90
80
80
70
60
50
40
30
20
3
3
4
4
4
6
6
8
10
14
Site Preparation Considerations Prior To Installation
• Split Phase 120/240 VAC Supply or single phase 120/208 VAC (Refer to Figure 1 and Figure 2).
• Both lines must have 120V between ground.
• Voltage supply must be grounded.
• Require 2 lines and 1 ground connection. Neutral is not used. (Refer to Figure 1 and Figure 2).
• Maximum output power: 19.2 kW @ 240 VAC or 16.6 KW @ 208 VAC.
• Built-in protection against overvoltage conditions and leakage current to ground.
• Use 90 °C wire copper conductors only.
• Field terminals accept wire between 3AWG and 14.
CoRe+ Max
TM
Installation Manual
