Floe INSTA-FLOAT - Insta-Float Bill of Materials; Parts List for Insta-Float (Without Winch)

511
-
04510
-
01
INSTA
-
FLOAT, WITHOUT WINCH
NO. PART NUMBER DESCRIPTION QTY.
1 001-05600-00 RIVET, AB6-8 3/16" x 1/2" 8
2 001-70215-00 HHCS, 1/2-13 x 3" 18-8 ss 2
3 001-71022-00 FLAT WASHER, 1/2" USS SS 18-8 12
4 001-74457-00 CB, 1/2-13 x 5-1/2" SS 8
5 001-76072-00 NUT, NYLOCK 1/2-13 ALUM. 2
6 001-76350-00 NUT, 1/2-13 ALUM 8
7 002-01311-00 CAP, AXLE BEAM - EXPRESS 4
8 010-05000-00 FLOAT, DOCK – 4’ x 6' x 12" 2
9 111-10002-00 CABLE, TOWING 1
10 111-10018-00 WELD’T, MAIN FRAME INSTA-FLOAT 1
THE “INSTA-FLOAT” BY FLOE
BILL OF MATERIALS
