Floe VSD 6000 - Page 16

16
STEP 7
512-65000-00 (VSD 5000)
-FASTEN TILTING BRACKETS (FIG. 1)
INSERT 1/2-13 x 4” BOLT, WASHERS, AND NUT INTO TILTING BRACKET.
ONLY TIGHTEN TO ENGAGE NYLOCK AND REMOVE FREE PLAY IN BOLT. DO NOT
DO NOT DO NOT
DO NOT
TORQUE.
TORQUE.TORQUE.
TORQUE.
-PLACE LOWER ACTUATOR BRACKETS
INSERT 3/8-16 x 4” BOLTS INTO BRACKET AND PLACE NUTS ON BOLTS (FIG. 2)
(FIG. 2)(FIG. 2)
(FIG. 2). DO
. DO . DO
. DO
NOT TIGHTEN.
NOT TIGHTEN.NOT TIGHTEN.
NOT TIGHTEN. NUTS WILL BE TORQUED IN STEP 8
NUTS WILL BE TORQUED IN STEP 8NUTS WILL BE TORQUED IN STEP 8
NUTS WILL BE TORQUED IN STEP 8
DO NOT TIGHTEN
FIG. 1
FIG. 2
