Floe VSD - Page 10

REPLACE THE FOAM INSERTS AS SHOWN (FIGURE 2.9 & 2.10). FOR AC DRIVE UNITS, KEEP THE
FOAM AWAY FROM THE HEATER BAND.
10
FIGURE 2.9
FIGURE 2.10
KEEP FOAM INSERTS AWAY FROM
HEATER BAND
