Ch. 2 Limitations
Avoid using the electric cable to lift or transport the pump. Use a stainless steel or nylon rope, suitable to sustain
the weight, to immerse the electropump. Two slots are present for allowing the anchoring of the head of the electro-
pump. Anchor the rope so that it balances the weight of the electropump.
It is advisable to connect the electric cable to the delivery with plastic straps, at a distance of about 3 m, when
using rigid piping.
It is also advisable to fi t automatic level controls to prevent the electropump from running without liquids and a
pressure gauge (suitable to the electropump model) to verify its performance during operation.
Ch. 3 INSTALLATION
DANGER
Electric
shock risk
All the operations that concern the installation must be carried out
with the pump disconnected from the energy supply.
Pumps in this series are not suitable for use in a swimming pool and
the relevant cleaning and servicing operations.
WARNING
The electropump cannot be used to move infl ammable or
dangerous liquids.
WARNING
Verify that the electropump never runs without liquids.
Technical Data SUB 6S SUB 8S
Mains voltage / Frequency 230-240 V ~ 50 Hz 230-240 V ~ 50 Hz
Absorbed power 800 Watt 1100 Watt
Type of protection / Insulation class IP 68 / F IP 68 / F
Delivery fi tting 41,90 mm (1”1/4 F) 41,90 mm (1”1/4 F)
Maximum fl ow rate 3.300 l/h 6.000 l/h
Maximum head 50 m 57 m
Maximum immersion depth 19 m 19 m
Power cable 22 m H07 RNF 22 m H07 RNF
Weight 12 Kg 13 Kg
Maximum dimension of pumped solid particles ≤ 1 mm ≤ 1 mm
Maximum admitted working pressure 11 bar 11 bar
Maximum amount of sand 50 gr/m
3
50 gr/m
3
Minimum diameter of the well 100 mm 100 mm
Maximum temperature of the pumped fl uid 40° C 40° C
Maximum number of starts per hour 30, uniformly distributed 30, uniformly distributed
Sound pressure level: less than 70 dB (A) - sound emission values obtained in conformity with the EN 12639 standard
Eventual malfunctions caused by the presence of sand in the pump are not covered under warranty as this can be
attributed to the transfer of more than 50g/m
3
of sand as indicated in the table.
GB
2
Technical Data SUB 4600/75 SUB 6000/75
Mains voltage / Frequency 230-240 V ~ 50 Hz 230-240 V ~ 50 Hz
Absorbed power 1100 Watt 1300 Watt
Type of protection / Insulation class IP 68 / F IP 68 / F
Delivery fi tting 41,90 mm (1”1/4 F) 41,90 mm (1”1/4 F)
Maximum fl ow rate 4.600 l/h 6.000 l/h
Maximum head 75 m 71 m
Maximum immersion depth 27 m 27 m
Power cable 30 m H07 RNF 30 m H07 RNF
Weight 12,5 Kg 12,5 Kg
Maximum dimension of pumped solid particles ≤ 1 mm ≤ 1 mm
Maximum admitted working pressure 11 bar 11 bar
Maximum amount of sand 50 gr/m
3
50 gr/m
3
Minimum diameter of the well 100 mm 100 mm
Maximum temperature of the pumped fl uid 40° C 40° C
Maximum number of starts per hour 30, uniformly distributed 30, uniformly distributed
