Flow-tronic Raven-Eye User Manual

Rue J.H. Cool 19a | B-4840 Welkenraedt | BELGIUM
Tel. : +32 (0)87 899 799 | Fax : +32 (0)87 899 790
E-mail : info@flow-tronic.com | www.flow-tronic.com
- 11 -
Figure 3: Sensor location near a curve, elbow or
junction
1 Acceptable upstream sensor location 3 Distance downstream: 10 x pipe diameter
2 Acceptable downstream sensor location 4 Distance upstream: 5 x pipe diameter
2
3
1
4
1
4
4
3
1
4
1
2
3
2
1
4
3
2
4
1
