4.3.2 Parameters
The RAVEN-EYE
®
acts as MODBUS ASCII slave serial device. The PLC is the master device.
The serial communication has the following characteristics:
 Communication (COM PORT): RS485
 Protocol: MODBUS ASCII
 Baud rate: 19200 bauds
 Number of bits: 8
 Parity: None
 Number of stop bits: 2
The RAVEN-EYE
®
uses the following MODBUS functions:
 03 “Read holding registers”
 16 “Preset multiple registers”
Used data types:
 Signed16 16 Bit signed integer
 Unsigned16 16 Bit unsigned integer
 Float32 32 Bit Floating Point
Word Order HI-LO = Hi Byte on lower register address
4.3.3 Measurement data „read only“
Table 2: Registers to be read
Adresse Modus Länge Typ Einheit Bezeichnung Kommentar
Address
Mode
Length
Type
Unit
Description
Comment
1000
R
2
float32
m/s
Velocity vQP
Velocity considering the quality parameters
1002
R 2 float32 m/s Velocity vQPF
Velocity considering the quality parameters and
the median filter
1004
R
2
float32
m/s
Velocity vAVG
Average velocity
1006
R
2
float32
m/s
Velocity vRAW
Raw surface velocity
1008
R 1 unsigned16
Sensor
identification
=0x0001
1009
R
1
signed16
VSN
Quality parameter (Velocity Spectrum Number)
1010
R
2
float32
SNR
Quality parameter (Signal to Noise Ratio)
1012
R
1
signed16
AGC
Quality parameter (Automatic Gain Control)
1013
R
1
signed16
NOT
Quality parameter (Number Of Trials)
1014
R
2
float32
°C
Temperature
Internal temperature of the sensor
1016
R
2
float32
%
Humidity
Internal humidity of the sensor
1018
R
2
float32
Bar
Pressure
Internal pressure of the sensor
1020
R 2 float32
Standard deviation
(σ)
Quality parameter
1022
R
2
float32
Amplitude (A)
Quality parameter
1024
R
2
float32
m
Level (h)
1026
R
2
float32
l/s
Flow rate (Q)
1028
R
1
unsigned16
Status
4.3.4 Level input „read & write“
Table 3: Registers to be read and written
Address
Mode
Length
Type
Unit
Description
Comment
4000
RW
1
Unsigned16
mm
Level
Used for flow calculation
