- 12 -
3.2.2 Sensor installation
CAUTION
Potential hearing loss risk. Hearing protection required. The level transducer emits ultrasonic sound
energy when powered. Ear protection must be worn when working within 1 meter of this device. Do
not point the transducer output towards ears during installation, calibration and maintenance.
Mount the RAVEN-EYE
®
sensor above the open channel on the wall of the manhole.
The RAVEN-EYE
®
sensor dimensions are shown in Figure 4 and Figure 5.
Figure 4: RAVEN-EYE
®
sensor
dimensions side view as installed
Figure 5: RAVEN-EYE
®
sensor dimensions top view as installed
