2.2 Product overview
The RAVEN-EYE
®
sensor measures the flow velocity in open channels using radar technology. The unit is
designed to withstand submersion during surcharge conditions. Optional level sensors provide the UNI-TRANS
monitor with the water level measurement during normal operation.
Figure 1: System
overview
1 RAVEN-EYE
®
Sensor 4 Mounting hardware (here: rotative handle)
2 Sensor cable 4 Level sensor mounting hardware
3 Level sensor
3
5
1
4
2
