Remove the Brass Nut, Washer, Spacer and Slotted Washer
from Faucet.
1 faucet base with tubing attached
1 small washer
1 brass nut
1 White plastic spacer
1 Slotted washer
Slide tubes through the opening for the
faucet until faucet base is resting on top
of sink.
Slip blue tube through small washer and brass nut. Position
white washer into place then tighten to within ¼” of top.
Slip slotted washer into position. Check orientation of
Faucet on top of sink. Tighten with a wrench.
DO NOT
OVERTIGHTEN. Some porcelain sinks could crack if over
tightened.
The three (3) tubes from the faucet will be cut to length
later in the installation.
Remove the piece of tubing from the top of the
faucet base by pulling upward. Needle nose pliers
can be used to grip the tube.
Insert spout of faucet into the opening in front of the black
lever and push down fi rmly.
