Flowmeter LDG - Model and Selection

Copyright Reserved, DONGYANG Corporation 5
3.0 MODEL AND SELECTION
Model Selection (See Table 1)
Table 1. Model Selection Guidance
Model Suffix Code
LDG-
□ /□ /□ /□ /□ /□ /□ /□ /□
Description
Diameter
10-2200mm
S Integrated type
combination
L Remote type
M Stainless steel 316
T Ti
D Ta
H Hastelloy alloy
P Pt
Electrode
Material
N Ni
0 No output
Signal Output
1 4-20mA/1-5KHz
X FEP
Liner material
F PTFE
0 No display unit
Display Unit
1 Display unit
0 No communication
1 RS485
Communication
2 MODBUS
0 No grounding ring
Grounding Ring
1 Grounding ring
Maximum Flow
(n)
Maximum flow
(measuring range) m
3
/h
