Flowserve Pump User Manual

MARK 3 USER INSTRUCTIONS ENGLISH 71569102 08-06
Page 61 of 68 flowserve.com
8.3 Mark 3 Sealmatic pump, Group 2
8.4 Mark 3 Lo-Flo, Group 2
Item Description
297 Seat
298 Lipseal
1100 Casing
1220 Cover
1220.1 Cover - repeller
2200 Impeller
2200.1 Repeller
4120 Gland
4200 Mechanical seal
4590.1 Gasket – cover
4590.2 Gasket – impeller
4590.9 Gasket – repeller cover
4610.10 O-ring - lipseal
4610.11 O-ring - repeller
6570.13 Screw – repeller cover
6572.2 Stud - gland
6580.2 Nut - gland
Notes:
See figure 6-30, GP3 Sealmatic wet end.
Item Description
1100 Casing
1220 Cover
