Troubleshooting Chart

Problem Probable Cause Corrective Action

Stem motion 1. Overtightened packing 1. Adjust packing box nuts to slightly over finger-tight

impeded 2. Service temperature is beyond 2. Reconfirm service conditions and contact factory

operating limits of trim design

3. Inadequate air supply 3. Check for leaks in air supply or instrument signal

system; tighten loose connections and replace

leaky lines

4. Malfunctioning positioner 4. Refer to positioner maintenance instructions

Excessive 1. Improperly tightened bonnet 1. Refer to step 3 of “Reassembling the Body”

leakage flange bolting section for correct tightening procedure

2. Worn or damaged seat ring 2. Disassemble valve and replace or repair seat ring

3. Worn or damaged seat or 3. Disassemble and replace gaskets

bonnet gasket

4. Inadequate actuator thrust 4. Check for adequate air supply to actuator; if air

supply is adequate, reconfirm service conditions

and contact factory

5. Incorrectly adjusted plug 5. Refer to steps 8 - 10 of “Reassembling the Body”

section for correct plug adjustment

6. Improper flow direction 6. Refer to original specifications or contact factory

7. Improper handwheel adjustment 7. Adjust handwheel until plug seats properly

acting as a limit-stop

Inadequate 1. Improper plug adjustment, 1. Refer to steps 8 - 10 of “Reassembling the Body”

flow limiting stroke section for correct plug adjustment

2. Malfunctioning positioner 2. Refer to positioner maintenance instructions

3. Service conditions exceed trim 3. Verify service conditions and consult factory

design capacity

Plug slams 1. Incorrect plug adjustment 1. Refer to steps 8 - 10 of “Reassembling the Body”

allowing improper cushion of section for correct plug adjustment

air between actuator piston

and yoke

2. Inadequate air supply 2. Check air supply to actuator; repair leaks and

remove any restrictions in supply line

3. Trim sized too large for flow rate 3. Install reduced trim

Valve does 1. Incorrect flow direction 1. Reconfirm direction and, if necessary, correct flow

not fail in cor- direction through valve

rect position
