Doc. No. 06EN003291 Rev. A B - 5 Model ST98 Flow Meter
APPENDIX B - GLOSSARY FLUID COMPONENTS INTL
Temp Display is The temperature display can be toggled on or off. If it is on, the results are
displayed on the second line of the normal operating mode window. If the Totalizer
is also on the totalized value and the temperature value will be alternately
displayed.
X. NAMUR OUTPUT
FAULT INDICATOR Menu Function.
NAMUR Flag is This function can be toggled on or off at this command.
Z. FLOW UNITS SELECT Menu Function.
Flow Units Are: Velocity Volume Mass
English SFPS SCFM LLB/HR
Metric SMPS NCMH KG/HR
Max = This is the maximum value, in the customer's units, that the instrument can display.
F.S. This is the full scale value, in customer units, which gives the maximum output
signal. This value can be input as anything less than the max value from above.
Zero This establishes at what flow rate the flow transmitter's output is at its minimum
output. It is 0.00 for zero based applications. For non-zero based applications the
zero is at minimum flow.
