FlowCam® 8000 Series Dynamic Imaging Particle Analyzer
7 of 39
Technical Specifications
Optics Options
8100
8400
4X Flow Cell
• Fused quartz
• FOV300, 300 µm depth x 1500 µm width
•
FOV600, 600 µm depth x 1750 µm width
10X Flow Cell
• Fused quartz
• FOV80
•
80 µm depth x 700 µm width
20X Flow Cell
• Fused quartz
• FOV50
• 50 µm depth x 350 µm width
Frame Rate
Up to 100 frames per second
Image Output
8-bit grayscale TIFF and 24-bit color TIFF
Objectives
4X, 10X, 20X
Lasers
NA
Excitation wavelengths:
Blue: 488 nm, 40 mW laser output
Green: 532 nm, 40 mW laser output
Red: 633 nm, 40 mW laser output
Laser Detector Bands (PMT Filters)
NA
Emission wavelengths:
Blue: Ch1 650 LP; Ch2 575/30
Green: Ch1 650 LP; Ch2 525/30
Red: Ch1 700/10; Ch2 650/10
Fluorescence Detectors
NA
Two photomultiplier tubes (PMTs) in
standard configuration
Fluidics
4X Minimum/Maximum Particle Size
25 µm–300 µm
10X Minimum/Maximum Particle Size
4 µm–100 µm
20X Minimum/Maximum Particle Size
2 µm–50 µm
Minimum Sample Flow Rate
0.01 mL/min
Maximum Sample Flow Rate
20 mL/min
Physical Specifications
Height: 15 in
Width: 14.125 in
Depth: 17.17 in
